Wherever food needs to be transported between floors, our range of dumbwaiters offers the ideal solution.
With loading at serving height and load carrying capacities of 50kg, 100kg and 250kg, the standard our Service Lifts cover most food transport applications.
To satisfy hygiene demands, Stainless steel shelves and floors are supplied as standard. Other stainless steel surface finishes are available as an option. A special seamless hygienic car is available as an option for more rigorous requirements.
Car protection is an important consideration when moving food as are the optional heated compartments.
Automatic "hands free" doors are available as an option on this range of lifts.
A bottom drive variant is available for applications where low headroom is a problem.
Dumbwaiter Service Lifts Specification:
| Usage | |
| Advantages | Ideal for bars & resturants, Low noise & vibrations, High hygiene standards, |
| Rated Loads (Persons/kg) | 50 - 250 |
| Machine Room | Above or to side |
| Maximum Travel | 15m |
| Maximum Stops | 6 |
| Car Speed (M/s) | 0.30 |
| Motor Type (Drive) | Traction drive |
| PIT Depth (Minimum) | 350 |
| Headroom (Minimum) | 1190 (50kg) to 1500 (250kg) |
